Specifications
Specifications
Picture Tube
Input Signal
Display Colours
Synchronisation
Range
Resolutions
Active Display
Area (Factory
Setting)
Active Display
Area (Full Scan)
Rated Voltage
Rated Current
Dimensions
Weight
43 cm (17 inch) flat square CRT, 39.6 cm (15.6 inch)
viewable image size, 0.25 mm mask pitch,
Medium-Short persistence phosphor, semi tint screen,
C C CRT with multi-layered, anti-static
ROMA LEAR
OptiClear coating
Analog 0.7 Vp-p 75 Ω Positive
Video
Sync Separate sync.
Horizontal sync.
Vertical sync.
Composite sync.
Analog Input: Unlimited colours
(Depends on the graphics board)
Horizontal 31 kHz to 94 kHz (Automatically)
Vertical 55 Hz to 160 Hz (Automatically)
Maximum 1600 x 1200 (75 Hz non interlaced)**
Recommended 1280 x 1024 (85 Hz non interlaced)*
Horizontal 306 mm (Active display area is
dependent upon the signal timing)
Vertical 230 mm (Active display area is
dependent upon the signal timing)
Horizontal 316 mm (Active display area is
dependent upon the signal timing)
Vertical 237 mm (Active display area is
dependent upon the signal timing)
AC 220-240 V 50/60 Hz
1.0 A
403 (W) x 430 (H) x 449 (D) mm
20.0 kg
E - 21
TTL Level
Positive/Negative
Positive/Negative
TTL Level
Positive/Negative
