E - 8

Quick Start

The following chart summarises the connection process for the
MultiSync P750.
For more details please turn to the following pages if you are connecting
to an IBM compatible, Macintosh compatible or other systems.
Is the BNC Input being used?
No
Set the D-SUB/BNC switch to the
down (push in) position.
Is the computer a Power Macintosh
6100/60?
No
Attach the signal cable of the moni-
tor to the video board/Apple adapter.
Connect the power cord of the
monitor to the power outlet and to
the monitor itself.
Turn monitor and computer on.
If necessary, use the OSM controls
for personal preference of the image.
Is the image correct?
Yes
Enjoy your monitor.
Yes
Set the D-SUB/BNC switch to
the up (raised) position.
Use the Apple HDI-45
Yes
cable adapter to attach the
monitors signal cable to the
Macintosh video output.
See the Trouble Shooting section
No
Yes
Call your NEC-Dealer
Quick Start
Problem solved?
No
