Sentiotec LINDEA-V-L-T-L Montageanleitung Seite 7

Installation instructions, only for experts
No.
Name
of items
Roof elements
2 Black roof element
1 Black roof element
1 Cover strip for roof element
1 Cover strip for roof element
Lindea interior decor
4 Lindea decor element
3 Lindea decor element
1 Lindea decor element with cut-out for exhaust air
2 Lindea decor element, roof
1 Lindea decor element, roof, with cover for sensor
1 Lime wood cover over glass (short side)
Interior fittings
1 Sauna bench with adjustable head piece – right
1 Sauna bench with adjustable head piece – left
2 Bench foot, left, right
4 Bench support slats
1 Sauna bench
1 Sauna bench
2 Sauna bench
2 Black bench feet
2 Black bench feet
4 Black bench feet
4 Bench feet struts
4 Bench feet struts
1 Floor grid
Lindea exterior decor
4 Lindea exterior decor element
1 Lindea exterior decor element
1 Lindea exterior decor element
1 Lindea exterior decor element
1 Lindea exterior decor element
1 Lindea exterior decor element
1 Lindea exterior decor element
p. 7/32
Dimensions in mm
2100x630x70
2100x840x70
2020x110x15
688x110x15
2020x656x40
2020x633x40
2020x656x40
1945x633x40
1945x633x40
633x40x40
1855x620x130
1855x620x130
620x935x60
570x40x40
1870x480x90
1870x410x130
735x760x90
450x480x40
450x390x40
760x450x40
520x80x20
250x80x20
600x340x40
2090x727x40
130x775x40
130x815x40
130x633x40
130x745x40
130x766x40
1960x727x40
EN
