Parts List - Sentiotec Lindea-V-L-T-L Montageanleitung

Installation instructions, only for experts

1.4. Parts list

No.
Name
of items
Base frame
1 Black base frame with ventilation aperture
1 Black floor frame
1 Black floor frame
Wall elements
5 Black wall element
2 Black electronic elements
1 Black ventilation / electronic element
8 Extra tongue and groove boards
1 Roof frame strip
1 Roof frame strip
1 Roof frame strip
1 Roof frame strip
Corner posts
2 Black corner post
1 Corner post for glass element with multiclip
and groove for glass – left
1 Corner post for glass element with multiclip
and groove for glass – right
1 Cover board for corner post with multiclip – left
1 Cover board for corner post with multiclip – right
2 Black spacer strips
1 Cover board with groove for glass – left
1 Cover board with groove for glass – right
Glass front elements
1 Black glass front element 1x 45° – left
1 Black glass front element 1x 45° – right
1 Black glass front element 1x 45° – left
1 Black glass front element 1x 45° – right
1 Glass door
1 Glass element with hole for door hinges
2 Glass element
p. 6/32
Dimensions in mm
2100x80x40
2045x80x40
1382x80x40
1995x663x70
1995x663x70
1995x663x70
663x15x55
1990x40x20
2045x40x20
2100x55x20
2045x55x20
1975x70x70
2035x110x55
2035x110x55
2125x150x55
2125x150x55
2090x55x40
2125x150x30
2125x150x30
2035x85x55
2035x85x55
718x85x55
718x85x55
1975x628x8
2006x680x8
2006x680x8
