Operating Instructions; Components And Parts (Standard Delivery) - Metabo BAS 317 Precision Betriebsanleitung

XA0058E1.fm

1. Components and Parts (standard delivery)

1
15
14
Front
1 Upper housing door
2 Setting knob for band saw
blade tension
3 Upper band saw wheel
4 Turn-lock fasterner, housing
door
5 Setting knob for blade guard
6 Blade guard
7 Upper blade guide
8 Band saw blade
9 Saw table
10 Fence guide extrusion, gradu-
ated
11 Lower band saw wheel
Downloaded from www.Manualslib.com

Operating Instructions

2
13 12 11 10
25
12
13
14
15
Rear
16
17
18
19
20
21
22
manuals search engine
ENGLISH
3
24
4
5
6
7
23
8
22
21
20
9
Chip case
Rip fence
Lower housing door
On/Off switch with emergency
stop
Quick release lever for band
saw blade
Blade tension indicator
Setting knob for blade tracking
adjustment
Motor
Machine base
Dust extraction port
Setting knob for drive belt
ENGLISH
26
23 Mitre fence
24 Table insert
25 Push stick
26 Stand
16
17
18
19
15
