Notes on documentation, Safety instructions, Product description
1

Notes on documentation

Where necessary, product information about this device can be downloaded from the RCM Inline Meter
EN
(RCM) website and from various QR codes via the display.
With the display switched on, from the Rittal menu page, you can display the first QR code by pressing
and holding down the "ESC" key for 3 s (fig. 5, item 1) until the display timeout is reached or any other
key is pressed. The "Up" key (fig. 5, item. 2) and the "Down" key (fig 5, item. 5) allow switching between
the different QR codes. The following information is stored in the QR codes:
"PDUi Info": contains the information printed on the RCM rating plate.
"Network Info": contains all set network information.
"System Info": contains all system information.
"Phase 1 Info", "Phase 2 Info" and "Phase 3 Info": contain the measured values of the associated
phase. These values are recalculated and refreshed every 3 seconds (approx.).
"Controller Info": contains the information printed on the RCM controller rating plate.
This Installation and Short User Guide is intended for experienced, trained specialists and contains only
the most important information concerning the assembly, installation and function of the RCM Inline Me-
ter.
1.1 Storing the documents
These instructions are an integral part of the product. They must be issued to everyone who works with
the unit and must always be available and on hand for operating and maintenance personnel.
2

Safety instructions

– Assembly and installation of the device may only be performed by experienced, trained specialists.
– The RCM housing must not be opened.
– The RCM must not come into contact with water, aggressive or inflammable gases or vapours.
– The RCM may only be operated within the specified environmental conditions (see section 9).
– The RCM is connected permanently to the mains power and does not have a main switch for the all-
pole mains power decoupling.
– The RCM is no substitute for a fault current circuit-breaker.
3

Product description

3.1 Functional description
The RCM Inline Meter is a differential current meter for use in IT racks. The differential current is meas-
ured at the infeed, i.e. for the entire IT rack. Other functions of the RCM Inline Meter include:
– Energy measurement at the infeed of each phase, i.e. the power requirements for an entire IT rack;
no switching function; with display and network interface.
3.2 Intended use
The RCM Inline Meter is used to measure differential current and therefore monitor electrically earthed
power supplies in IT racks, and is designed for permanent installation in IT racks. It must not be used
at locations where children may be present and is envisaged for use only in a restricted access area
(e.g. lockable rack).
22
Note:
Further safety instructions in all EU languages can be found on page 2 to 4.
