NOTICE:
Attach any of the attachments to the lawn
mower before mowing.
EN ◾
To Attach/Remove the Grass Bag (Fig. J)
NOTICE:
Remove the pre-installed mulching insert in
the mower before attaching the grass bag to the mower.
◾
To Attach/Remove the Mulching Insert (Fig. K)
◾
To Attach/Remove the Side Discharge Chute (Fig. L)
ADJUSTING THE CUTTING HEIGHT (Fig. M)
WARNING:
Keep your feet away from the deck when
adjusting its height. The mower can be set to 5 cutting
heights between 25mm and 80mm. Choose the proper
cutting height according to the types and conditions of
the grass.
NOTICE:
When moving the tool, make sure the cutting
height is adjusted at the position of 3 or higher. Failure to
do so, could result in the damage of the blade.
ATTACHING/DETACHING THE BATTERY PACK (Fig. N)
CHARGE BEFORE FIRST USE.
WARNING:
If any parts are broken or missing, do
not attempt to attach the battery pack to the mower or
operate the mower until the broken or missing parts are
replaced. Failure to do so could result in serious injury.
◾
To Attach
Push the battery pack into the battery compartment
until you hear a "click".
◾
To Detach
Depress the battery-release button in the battery
compartment.
NOTICE:
Make sure that the latch on the mower snaps
into place and that the battery pack is secured to the
mower before starting operation.
STARTING/STOPPING THE MOWER
WARNING:
The operation of any lawn mower
can result in foreign objects being thrown into your or
others' eyes, which can damage eyes severely. Always
wear safety glasses while operating the mower, or while
performing any adjustments or repairs on it.
WARNING:
Do not use the mower in the rain.
WARNING:
Ensure that other people and pets remain
at least 30m away from the mower when it is in use.
12
56 VOLT LITHIUM-ION CORDLESS MOWER — LM2000E
WARNING:
The blade will continue to rotate for
a few seconds after the mower is turned off. Allow the
motor/blade to stop rotating before starting it again. Do
not rapidly turn the mower off and on.
NOTE:
The motor cannot be started unless:
◾
The handle is locked into one of the operating positions
(Fig. O).
◾
The side rails are fully extended (Fig. P).
◾
Both green handle-locking clamps are securely closed
(Fig. Q).
SAFETY KEY
In order to prevent accidental start-up or unauthorized
use of your cordless mower, a removable safety key has
been incorporated into the design of your mower. The
mower will be completely disabled when the safety key
has been removed from the mower.
DANGER:
Rotating blades can cause serious injury.
To prevent serious injury, remove the safety key when
the mower is unattended, or when adjusting, cleaning,
servicing, transporting, lifting, or storing the mower.
To Start (Fig. S)
1) Attach the battery pack to the mower and close the
battery cover.
2) According to Fig. R, insert the safety key into the slot
and then depress the safety key.
3) With the safety key depressed, pull the bail switch
upward to the handle and release the safety key.
To Stop (Fig. T)
1) Release the bail switch.
2) The electric brake in the Automatic Braking
Mechanism will stop the blade rotation within 3
seconds of the bail switch release.
LED WORK LIGHTS ON THE MOWER
Press the switch button (Fig. C-21) to turn on/off the LED
work lights in the front of the battery compartment.
POWER INDICATOR ON THE MOWER (Fig. U )
The mower is equipped with a power indicator (Fig. C-20)
to indicate the charge status of the battery pack and the
working status of the mower. The power indicator will
illuminate when the blade is rotating or when the LED
work lights are turned on.
