Power
Indicator on Meaning
Mower
Mower is working
properly; battery
Shining green
has at least 15%
of its charge
Shining red Low battery
The battery is
Flashing red
nearly depleted
The mower or the
Shining
battery pack is
orange
overheated
Flashing The mower is
orange overloaded
MOWER OVERLOAD PROTECTION
To prevent damage due to overload conditions, do not try
to cut too much grass at one time.
Your mower has built-in overload circuit protection.
When the mower is overloaded, the power indicator on
the mower will blink orange. The mower can endure a
short time of overload before turning itself off. You can
slow your speed to reduce the load or raise the cutting
height of the mower; otherwise the protection circuit will
automatically turn off the mower. Release the bail handle,
wait for a few seconds and try again.
BATTERY HIGH TEMPERATURE PROTECTION
The battery pack will generate heat during operation. The
heat dissipates more slowly in hot weather. If the battery
temperature exceeds 70°C during operation, the protec-
tion circuit will immediately turn off the mower to protect
the battery pack from damage. The power indicator on
the mower will shine orange. Release the bail handle, wait
until the battery pack cools down to approximately 67°C ,
then restart the mower.
MAINTENANCE
Action
remove the safety key and battery pack from the mower
before cleaning or performing any maintenance.
N/A
replacement parts. Use of any other parts may create
Stop the mower and
a hazard or cause product damage. To ensure safety
charge the battery
and reliability, all repairs and replacements should be
pack
performed by a qualified service technician.
Stop the mower and
charge the battery
CLEANING THE MOWER
pack
Remove the battery
from the mower,
expose the mower to water. Always remove the safety key
move them to the
and battery pack when servicing or transporting the mower.
shade and cool them
The underside of mower deck should be cleaned after
at least 15 minutes
each use, as grass clippings, leaves, dirt and other debris
Slow down your
will accumulate.
pace or raise up
the cut height to
Remove any build-up of grass and leaves on or around
decrease the load
the motor cover (do not use water). Wipe the mower clean
with a dry cloth.
REMOVING/INSTALLING THE BLADE
heavy gloves or wrapping the cutting edges with rags or
other materials when performing any maintenance on the
mower blade. Always remove the safety key and battery
pack when servicing or transporting the mower.
◾
◾
STORAGE THE MOWER
◾
56 VOLT LITHIUM-ION CORDLESS MOWER — LM2000E
WARNING:
To avoid serious personal injury, always
WARNING:
When servicing, use only identical
WARNING:
To reduce the risk of electric shock, do not
WARNING:
Always protect your hands by wearing
To Remove the Blade (Fig. V)
To Install the Blade
Following the assembly sequence in Fig. W, with the fan
blade towards deck and the bulge on the blade towards
outside, align the through holes in the fan with the holes in
the blade (Fig. X) and then tighten the blade as Fig. Y shown.
Fig. W parts description see below:
W-I Fan W-4
W-2 Inner Flange W-5
W-3 Outer Flange W-6
NOTICE:
The recommended torque for tightening the
blade bolt is 49-59Nm.
Remove the battery pack from the mower and store it
in a cool, dry and clean location. Do not store it next to
corrosive materials, such as fertilizer or rock salt.
EN
Bolt
Blade
Blade Bulge
