Setting Up The Loudspeakers - T+A CRITERION TCI C 2 Betriebsanleitung

All TCI series speakers are supplied complete with
various accessories, and these include spikes and
furniture glides, designed to couple the low-frequency
sound output to the listening room floor. If you are
considering the use of spikes or furniture glides, be sure
to read the following notes:
• The points of spikes may damage delicate floor
surfaces (e.g. parquet flooring or tiles).
• The spikes are extremely sharp, and therefore
capable of inflicting injury. Please handle them with
the greatest care, and keep them well away from
children.
• When children are playing they tend to be unaware of
danger. For this reason you should either set up your
loudspeakers where children do not usually play, or
provide some means of ensuring that the speakers
cannot topple over.
To fit the spikes or furniture glides, place the
loudspeaker at its final location, and carefully lay the
cabinet on its side.
Set the speakers upright again in the desired position.
The furniture glides can be screwed in or out slightly to
compensate for any slight irregularity in the floor. The
glides can then be locked in place at the desired position
by tightening the nuts.
Downloaded from www.Manualslib.com

Setting up the loudspeakers

Screw the
spikes into
threaded holes in
the bottom of the
cabinet as shown
in the illustration.
Screw them in as
far as they will go.
Set the speakers
upright again in the
desired position.
or
First screw the M6
nuts (supplied)
onto the threaded
shank of
furniture glides.
Screw the furniture
glides into
threaded holes in
the bottom of the
cabinet.
manuals search engine
Example:
7.1 loudspeaker set with CRITERION TCI loudspeakers
four
the
the
the
20
