Quick Start

To attach the MultiSync FP1355 monitor to your system, follow these
instructions:
1. Turn off the power to your computer.
2. If necessary, install the display card into your system. For more
3. For the PC or Mac with DVI Analog output: Connect the DVI end of
01b_english
Downloaded from www.Manualslib.com
information, refer to the display card manual.
the VGA to DVI-A signal cable to the connector of the display card in
your system (Figure A.1). Tighten all screws.
For the PC with VGA Analog output: Connect the VGA end of the
VGA to DVI-A signal cable to the connector of the display card in your
system (Figure A.2).
For the Mac: Connect the MultiSync Macintosh cable adapter (not
included) to the computer (Figure B.1). Attach the VGA end of the
VGA to DVI-A signal cable to the Macintosh cable adapter
(Figure B.1).
NOTE: Some Macintosh systems do not require a Macintosh
cable adapter.
Figure A.1
2
manuals search engine
Figure A.2
English-2
