NEC MultiSync FP1355 Bedienerhandbuch Seite 12

Controls
OSM (On-Screen Manager) control buttons on the front of the monitor
function as follows:
To change DVI/D-SUB signal input, press the RESET button.
NOTE:
EXIT
CONTROL L/M
CONTROL -/+
PROCEED
D-SUB/DVI-A
RESET
NOTE:
When OSM controls are activated, icons are displayed at the top of the
menu. If an arrow (¡) is displayed in a sub-menu, it indicates further
choices are available. To enter a sub-menu, press PROCEED.
Brightness: Adjusts the overall image and background screen
brightness.
Contrast: Adjusts the image brightness in relation to the background.
01b_english
Downloaded from www.Manualslib.com
OSM must be closed in order to change DVI/D-SUB signal
input.
Main Menu
Exits the OSM menu.
Moves the highlighted
area up/down to select
one of the controls.
Moves highlighted area
left/right to select one of
the controls.
Has no function.
Without OSM menu
screen, push to select the
signal input connector,
D-SUB or DVI-A.
Resets all the controls
within the highlighted
menu to the factory
setting.
When RESET is pressed in the main and sub-menu, a
warning window will appear allowing you to cancel the reset
function.
Brightness/Contrast Controls
4
manuals search engine
Sub-Menu
Exits to the OSM main menu.
Moves the highlighted area
up/down to select one of the
controls.
Moves the bar in the - or +
direction to decrease or
increase the adjustment.
Only executes control or
enters sub-menu.
Resets the highlighted control
to the factory setting.
English-4
22.02.2001, 14:12 Uhr
