Sides Left/Right (pincushion balance): Decreases or increases the
curvature of the sides either to the left or right.
Sides Tilt (parallelogram): Decreases or increases the tilt of the sides
either to the left or right.
Sides Align (trapezoidal): Decreases or increases the bottom of the
screen to be the same as the top.
Rotate (raster rotation): Rotates the entire display clockwise or
counterclockwise.
Moiré Canceler: Moiré is a wavy pattern which can sometimes appear
on the screen. The pattern is repetitive and superimposed as rippled
images. When running certain applications, the wavy pattern is more
evident than in others. To reduce moiré, adjust the level by using
-/+ control buttons.
Basic Convergence: Aligns all three colours (R,G,B) to form a single
colour (white). The purpose of this control is to ensure that a white line
drawn on the screen is as crisp and clear as possible.
• Use the Horizontal control to adjust the alignment of the white lines in
• Use the Vertical control to adjust the alignment of the white lines in
Corner Correction:Allows you to adjust the geometry of the corners of
your display – Top, Top Balance, Bottom or Bottom Balance.
Linearity: This selection allows you to adjust the spacing of the area on
the screen. The purpose of this control is to ensure that a one-inch circle
is a true one-inch circle wherever it is on the screen. The best way to
determine the vertical linearity is as follows:
• Draw equally spaced horizontal lines using a drawing application that
• Use the Vertical Balance control to adjust the lines near the top and
• Use the Vertical control to adjust the spacing between the lines near
01b_english
Downloaded from www.Manualslib.com
Tools 1
the up/down direction.
the left/ right direction.
has a ruler.
bottom of your screen.
the center and top of your screen.
