- Safety devices:
1) Electronic control for monitoring boiler water
and flue gas temperatures. Includes additional
EN
overheating sensor (STB thermostat);
2) Safety heat exchanger – in case of overheating,
cold water passes through it to reduce boiler
1. Microprocessor control;
2. Safety heat exchanger;
3. Thermal mineral wool insulation;
4. Water jacket;
5. Fuel loading chamber;
6. Gasification chamber;
7. Flue damper lever

11.2. Components of the combustion chamber of PyroBurn Alpha boiler

Diagram 11. Components of the combustion chamber of PyroBurn Alpha 18 kW
No code
1 31080031000001 Side element of upper combustion chamber - 18 kW
2 89080031000035 Nozzle - 18 kW
3 89080031000030 Rear element of bottom combustion chamber - 18 kW
4 89080031000031 Bottom element of bottom combustion chamber - 18 kW
5 89080031000038 Side element of bottom combustion chamber - 18 kW
6 89081282000016 Protective steel plate
Diagram 12. Removable parts of the combustion chamber of PyroBurn Alpha 18 kW
No code
1 31080031000002 Side element of upper combustion chamber - 25 kW
2 89080031000006 Nozzle - 25 kW
3 89080031000005 Rear element of bottom combustion chamber -25 kW, 40 kW
4 89080031000001 Bottom element of bottom combustion chamber – long - 25 kW, 40 kW
5 89080031000002 Bottom element of bottom combustion chamber – short - 25 kW, 40 kW
6 89080031000012 Side element of bottom combustion chamber -25 kW, 40 kW
7 89081282000014 Protective steel plate
No code
1 31080031000002 Side element of upper combustion chamber - 40 kW
2 89080031000009 Nozzle - 40 kW
3 89080031000005 Rear element of bottom combustion chamber - 25 kW, 40 kW
4 89080031000001 Bottom element of bottom combustion chamber – long - 25 kW, 40 kW
5 89080031000002 Bottom element of bottom combustion chamber – short - 25 kW, 40 kW
6 89080031000012 Side element of bottom combustion chamber - 25 kW, 40 kW
7 89081282000015 Protective steel plate
TECHNICAL PASSPORT INSTALLATION and OPERATION MANUAL
Diagram 10. Components of PyroBurn Alpha boiler
Model PyroBurn Alpha 18 kW
Table 8.1
Model PyroBurn Alpha 25 kW
Table 8.2
Model PyroBurn Alpha 40 kW
temperature * ;
3) Safety valve 3 bar
* Requires connection to the water mains by means
of thermostatic valve
8. Hot water outlet
9. Chimney flue;
10. Draught fan;
11. Primary air flap;
12. Secondary air flap;
13. Cold water inlet
14. Drainage
Table 7
14
pcs.
2
1
1
1
2
4
pcs.
2
1
1
1
1
2
6
pcs.
2
1
1
1
1
2
6
