SPECIFICHE TECNICHE
TECHNICAL DATA
TECHNISCHE ANGABEN
ASP48
Channels
Input impedance
Max input level
CMRR
Phantom power
Electronic output max level
Electronic output impedance
Electronic output max load
Transformer output max level
Transformer output impedance
Transformer output max load
Gain switch
Pad switch
Line/Mic switch
43.8mm
PSU2
AC Input
Fuse
DC outputs
DC indicators
Headroom Meter (via Cue
momentary switch on ASP48)
ASP48
Italiano
4 independent or internally interconnected
2Kohm (Mic), 10Kohm (Line)
+20dBV (Mic), +40dBV (Line)
>90dB @ 1KHz (Mic), >75dB 50Hz-10KHz
+48VDC
+3dBm (Mic), +23dBu (Line)
<23ohm (Mic), <100ohm (Line)
200ohm (Mic), 600ohm (Line)
+3dBu
<50ohm
600ohm
-20, -10, 0, 10 20, 30dB
0/-20dB
+20/0dB
PSU2
Italiano
See on the rear panel
See on the rear panel
+25V unregulated @ 4A max: low ripple
-25V unregulated @ 4A max: low ripple
+48V ±5% regulated @ 500mA max
3 LEDs for each supply (post fuse), +25V -25V +48V
12 LED meter: -30, -20, -15, -10, -5, -2, 0, +2,
+5, +10, +15, Clip
88.3mm
ASP48
English
Frequency response
Noise (E.I.N.) 20Hz-20KHz
Distortion (T.H.D.)
Clip LED
Connectors
Power
Dimensions (WxHxD)
Weight
PSU2
English
Headroom monitor (via Cue
momentary switch on ASP48)
Dimensions (WxHxD)
Weight
13
ASP48 - PSU2
20Hz-20KHz (<±0.3dB)
<-108dBu (-20dB gain)
<-117dBu (-10dB gain)
<-121dBu (0dB gain)
<-122dBu (10dB gain)
<-122dBu (20dB gain)
<-122dBu (30dB gain)
<0.05% 20Hz-20KHz @ 10dB below clip
2dB below clip
XLR balanced
±25VDC, +48VDC from PSU2 only
483x43.8x193mm
3.6Kg - 8lbs
Connector: 2 x 1/4" stereo/mono Jack
Load impedance: 30ohm to 600ohm
Max output: 860mW rms (30ohm)
750mW rms (200ohm)
483x88.3x240mm
8.5Kg - 18.7lbs
Deutsch
Deutsch
