Installation & Battery Replacement; Operation - Simons Voss Technologies ST10.080070 Kurzanleitung

PinCode-Tastatur (offline)
Using a pro-
Open the programming app or task list and follow the instructions.
gramming
app or task
list
6 Installation & battery replacement
The PIN code keypad can be installed using the supplied installation
accessories.


Install the PIN code keypad at a distance of up to 20 cm from the
locking device.
The PIN code keypad housing must be open to replace the batteries.
You will need a "TX6" Torx screwdriver (not included in the supply
package) to do so. Replace all batteries with new Murata, Panasonic or
Varta CR 2032 (3V) batteries.

7 Operation

ü
ü
EN
You can use the enclosed special adhesive pad to attach the PIN
code keypad, making installation quick and easy.
We recommend using the supplied screws to secure the
component. You will need a "TX6" Torx screwdriver (not included in
the supply package) to open the housing.
The PIN code keypad has now been successfully configured.
(master PIN & user PIN)
The PIN code keypad has been programmed correctly.
6. Installation & battery replace-
ment
27 / 108
