hanseatic HWC24FCBH Gebrauchsanleitung Seite 45

C
B
Space required according to the
appliance dimensions
A: 470 mm B:
C: 100 mm D:
E: 915 mm F:
G: 50 mm H:
I: 770 mm
– To prevent a flammable gas-air mixture
from forming following any leakage in the
refrigeration circuit, the installation space
must have a minimum size of 2.2 m³.
– The appliance must only be placed on a
level and firm surface. The surface must be
strong enough to support the appliance's
weight when fully laden.
– Suitable locations are dry, well-ventilated
areas that are cool if possible.
G
A
D
– Unsuitable locations are ones with direct
830 mm
– The following minimum distances must be
472 mm
100 mm
130 °
– If you would like to reduce these distances,
– If underfloor heating is installed at the set-
Start-up
F
G
H
I
sunlight or which are directly next to an
oven, hob or radiator.
maintained:
– from electrical hobs
– from oil and coal burning stoves 30 cm
– from other cooling appliances
– from washing machines/
dishwashers
you can fit an insulation plate between the
appliances.
up location, place the cooling appliance on
an insulation plate made from solid mate-
rial.
Page EN-17
E
5 cm
5 cm
5 cm
