Where negative values are permitted, the
highest digit will switch from "9" to"–"
and only then to "0".
Press the key to switch to the next
digit.
5 5 . . 2 2 I I n n p p u u t t P P a a r r a a m m e e t t e e r r s s f f o o r r I I n n s s t t a a n n t t a a n n e e o o u u s s
v v a a l l u u e e
All set-ups related to the input signal and
the corresponding displayed value are
carried out here. The displayed value
5 5 . . 2 2 . . 1 1 S S e e l l e e c c t t r r a a n n g g e e f f o o r r t t h h e e i i n n p p u u t t s s i i g g n n a a l l
Menu <–>
press key to accept the selection
5 5 . . 2 2 . . 2 2 S S e e t t t t h h e e d d e e c c i i m m a a l l p p o o i i n n t t f f o o r r t t h h e e I I n n s s t t a a n n t t a a n n e e o o u u s s v v a a l l u u e e
Menu <–>
press key to accept the selection
www.kuebler.com
Selection

Display range

2 ... 10 V
-10 ... +10 V (–10,500 ... 10,500)
0 ... 20 mA (–01,000 ... 21,000)
4 ... 20 mA
0 ... 10 V
Selection Range
–19999 ... 99999
0,0 –1999,9 ... 9999,9
0,00 –199,99 ... 999,99
0,000 –19,999 ... 9999,9
0,0000 –1,9999 ... 9,9999
Enter value: Press the
value will be stored. The next menu item
appears.
is displayed from the input signal via the
scaling slope.
(–0,500 ... 10,500)
(01,500 ... 10,500)
(03,000 ... 21,000)
(–0,500 ... 10,500)
The position of the decimal
point has no influence on
the measuring accuracy.
The maximum display value
must be within the display
range. After the decimal
point is set up, the leading
zeros in the display will be
suppressed.
key, the
Page 11
