CMi C-AMBS-7.2 Set Originalbetriebsanleitung Seite 36

GB
Note: The Li-Ion battery pack can be
charged at any time without affecting the
lifetime of the unit. Interrupting the charging
process will not damage the battery pack.
• The battery pack must be charged prior to the
first start-up (charging time: ► Technical data –
p. 37).
– Plug the power supply into a mains socket.
► P. 3, item 2
– Push the connector of the power supply into the
socket (8).
The charging status is displayed by the control
lights (3).
Checking the remaining capacity of the battery
The remaining capacity of the battery is displayed by
the control lights (3).
Operation
Check before switching on!
Check to make sure the unit is in a safe operating
condition:
– Check to make sure there are no visible defects.
– Check to make sure all unit components are cor-
rectly mounted.
Inserting a tool
► P. 4, item 3
CAUTION! Risk of injury! Only use tools
approved by the manufacturer!
Never use damaged tools. Always check
tools for tears and other damage before
mounting.
Only use tools that are appropriate for the
material you are processing.
Only use tools with a permitted revolution
that is at least as high as the idle revolutions
of the unit.
1. Fit the appropriate collect chuck for the tool into
the tool holder.
2. Screw the coupling nut into place.
3. Fit the required tool into the collet chuck.
4. Press and hold down the locking button.
5. Tighten the coupling nut with the supplied mount-
ing wrench.
Switching on and off
NOTICE! Risk of damage to the unit!
The motor may overheat in the event of per-
manent heavy loads and low revolutions.
Run the motor at higher revolutions in idle
to allow it to cool down.
– Switching on: Push the On/Off switch (4) to posi-
tion [I].
– Switching off: Push the On/Off switch (4) to posi-
tion [0].
Electronic control of rotational speed
The appliance is equipped with an electronic rota-
tional speed control.
36
NOTICE! Risk of machine damage! The
motor can overheat when running at low
speeds under continuous heavy load. Cool
off the motor by running at high speed with-
out a load.
► P. 4, item 4
– Set the required speed using the buttons (2).
• The set speed is indicated by the control
lights (3).
Speed setting Speed range
5 5000 min
15 15000 min
20* 20000 min
25 25000 min
30 30000 min
*) The speed is always reset to 20,000 rpm when switching on the
device.
Mounting the protective hood
► P. 4, item 5
– Unscrew the screw cap (6).
– Screw on the protective hood (9).
– Turn the protective hood to protect the user from
chips, sparks, etc.
Notes on using the device
WARNING! Risk of injury! Do not tilt work
piece and tool. Risk of injury due to flying
broken pieces!
Note: Excessive pressure does not result in
greater performance, instead it causes
greater wear on the tools.
– Always hold work pieces securely or clamp into
place.
– Do not tilt work piece and tool.
– When milling or engraving hold the device as if it
were a writing implement.
– For coarse work, hold the device as if it were a
hammer.
• The following guidelines apply to the tool revolu-
tions:
– Plastic and materials with a low melting point
must be processed at lower revolutions.
– To polish or clean using wire brushes select a
low revolution level in order to prevent dam-
ages by the brushes.
– Wooden materials should be processed at
higher revolutions.
– Iron and steel should be processed at higher
revolutions.
– Dampening the tool with petroleum or another
suitable lubricant will prevent shavings from
sticking to the cut surfaces.
