Installing Axkid One car seat in
the vehicle
Before installing Axkid One car seat in your vehicle, minimize its size by releasing the legroom
1
adjustment button (N) and slide the seat towards the front brace (D). Fold down the support-leg (R)
until a click can be heard and the support-leg position indicator (P) turns green.
Release the front brace release button (C) and fold the front brace (D) towards the seat. Keep holding
2
the front brace (D) with one hand and grab the back handle (O) with the other hand and lift the Axkid
One car seat into your vehicle with the front brace (D) first and then turn it to a rear-facing position.
Push the ISOFIX connectors (Y) into the ISOFIX connection points in the vehicle until you hear a click
3
and both ISOFIX locking indicators (V) turn green.
Let go of the front brace (D) which will start tensioning itself against the vehicle seat. When it stops,
4
turn the front brace knob (K) clockwise until you feel and hear a click, the front brace (D) should now
be firmly pressed against the vehicle seat. The front brace knob (K) has a built-in torque limiter and
the click indicates that the front brace (D) is tightened correctly and cannot be tightened any more.
Push the support-leg button (I) and pull the support-leg (R) downwards until it is in contact with the
5
vehicle floor. Let go of the support-leg button (I) and lift the car seat upwards to further extend the
support-leg (R) until you hear a click. The support-leg (R) should now be locked and firmly pressed
against the vehicle floor. Note: The Axkid One car seat is equipped with a beeping sound indicator (S)
that will keep beeping until the support-leg (R) is firmly pressed against the floor, indicating a correct
installation.
Push the ASIP pad (G) into the slots on the ASIP connector (J) and slide downwards, the ASIP pad
6
(G) will click into place. If there is a plastic cover on the ASIP connector (J), remove it and place it on
the ASIP connector (J) on the opposite side of the seat before fitting the ASIP pad (G). Make sure the
ASIP pad (G) is attached on the side of Axkid One car seat that is closest to the vehicle door.
