TECHNICAL DATA

Lens diameter .................................................60 mm
Focal width . .....................................................700 mm
31.7mm eyepiece K . .....................................20 mm, 12.5 mm, 9 mm, 4 mm
Maximum magnification ............................262.5 times
Finder scope ....................................................6 x 25 mm
Erecting lens ....................................................1.5 x
Aluminium tripod with altazimuthal mounting, moon filter, deflection mirror, storage tray,
vernier adjustment, instructions, star chart, carrying case, compass
As our products are constantly being further developed and improved, design and technical
changes are possible.
The refractor telescope is designed for private household use. It is unsuitable for commercial use.

SCOPE OF DELIVERY AND DESCRIPTION OF PARTS

• D eflection mirror
4 exchangeable 31.7 mm "K" = Kellner eyepieces: 20 mm, 12.5 mm, 9 mm and 4 mm and a
screw-in moon filter (no picture) – not usable as a solar filter. Magnification as per table.
• "K" eyepieces
T he device is equipped with "K"= Kellner eyepieces,
a triple-lens system, which allows higher resolutions
than conventional "H" eyepieces
• 6 x 25 mm finder scope with
cross hairs (for more a detailed
description, see following text)
• Instructions for building a solar projection screen
