4 | Assembly and Mounting

Check the LED luminaire before installation to ensure it is complete and shows no
signs of damage. Do not use the luminaire or accessories if they are damaged, as
there is a risk of injury.
The LED luminaire comes fully assembled. Optional there are following mounting ac-
cessories for this luminaire:
Luminaire bracket PROFILED und SYSTEMLED for T-slots, pair 240400-01
Luminaire bracket PROFILED und SYSTEMLED for rotatable
mounting , pair
When mounting the luminaire, make sure that the luminaire is
fastened securely and stably. If the luminaire falls down, its weight
poses a risk of injury!

5 | Connection and initial operation

The luminaire is connected with a 230V AC electric power supply system via the cable
with SCHUKO plug.
10 | BA PROFILED AC_ . BA 11/2019
PROFILED AC 150x14-03, luminaire without dimming
To turn on the luminaire, activate the switch on the side of the
luminaire body and set it to [ I ].
PROFILED AC 150x14-04, luminaire with dimming
To turn on the luminaire, activate the push button on the side of
the luminaire body. Hold on the push button for setting of the light
intensity. A repeated pushing of the button turns the light off.
Item no.
240400-02
