Multi-Element Boundary Microphone

General Description

Shure MX396 Dual-Element and Tri-Element microphones provide full
coverage of large tables with fewer microphones, and feature a low
profile design. This makes them ideal for use in boardrooms and other
installations where aesthetics are important.
Placement
Important:
Align the Shure logo as shown for proper coverage.
MX396/C-DUAL
2 x 130° @ -3 dB
MX396/C-TRI
300° @ -3 dB
Features
• Low profile, aesthetic design
• Wide dynamic range and smooth frequency response
• Configurable mute switch with logic output
• Logic input for external LED control
• RF filtering with CommShield
MX396/C-DUAL & TRI
MX396/C-TRI
360°
technology
®
