34 | English
The indicator for left rotation 6 lights up when the On/Off switch
8 is actuated and the motor is running.
Setting the torque
The required torque can be preselected in 20 steps with the torque prese-
lection ring 3. With the correct setting, the insert tool is stopped as soon
as the screw is screwed flush into the material or when the set torque is
reached.
Select a higher setting when driving out screws, or set to the symbol
"Drilling".
Switching On and Off
To start the machine, press the On/Off switch 8 and keep it pressed.
The power light 9 lights up when the On/Off switch 8 is slightly or com-
pletely pressed, and allows the work area to be illuminated when lighting
conditions are insufficient.
To switch off the machine, release the On/Off switch 8.
To save energy, only switch the power tool on when using it.
Adjusting the Speed
The speed of the switched on power tool can be variably adjusted, de-
pending on how far the On/Off switch 8 is pressed.
Light pressure on the On/Off switch 8 results in a low rotational speed.
Further pressure on the switch results in an increase in speed.
Fully automatic spindle locking (Auto-lock)
When the On/Off switch 8 is not pressed, the drill spindle and thus the
tool holder are locked.
This enables screws to be screwed in, even when the battery is empty and
allows for the machine to be used as a screwdriver.
Run-on Brake
When the On/Off switch 8 is released, the chuck brakes to a stop, thus
preventing the run-on of the tool.
When driving in screws, wait until the screw is screwed in flush with the
material and then release the On/Off switch 8. By doing so, the head of
the screw does not penetrate into the material.
