"Group I" / 9 to 18 kg. / With ISOFIX and Top tether
IMPORTANT: First please check if there are 2 ISO FIX anchorings in the perpendicular intersection of the
vehicle seat back and seat cushion, and the user-ready top tether anchoring behind the vehicle seat. Pic. 7.1
Tips: The user-ready tether anchorage usually permanently installed on the inner rear luggage shelf or on the
vehicle floor. For details you could read your vehicle guidelines or contact the vehicle manufacturer. Pic. 8
Step 1. Press the Release button to release the ISO FIX connectors. Than you can hear an audible sound
"click" Picture 9
Step 2. Push the ISO FIX connectors directly into the anchorages until you hear an audible sound "click".
Picture 10
Tip: If the ISOFIX connectors are correctly installed, the Release button will pop out, and you can see a clear
green mark on it. Picture 10.1
Step 3. Press the Release button ( Picture 9) and push firmly the child seat towards the car seat backrest.
During this moving the ISOFIX system will tighten the child seat to the car seat backrest and you will hear a
"Click"sound . Ensure that the child seat is firmly pressed to the car seat backrest. Check the ISOFIX release
button again and ensure the latching indication shows GREEN. Picture 10.2
Step 4. Grasp the seat body to check the seat if it is fastened tightly or shakes. If the seat shakes and the
ISOFIX connectors are pulled out, please repeat the above steps and install it again.
Step 5 Pull out the Top tether and press the Tether strap release button to extend the strap until it is long
enough to hook the User-ready tether anchorage behind. Picture 11.3 Guide the top tether through the
headrest of the car.
Step 6. Hook the Tether strap hook onto the User-ready anchorages. Check there maybe are 3 anchorages
for the hook, please find one in your favor. Picture 8 ; 11.4
Step 7. Pull the Tether strap on another end back to tighten the Top tether. Picture 11.5
CAUTION: If the Top tether is tightened favorably and correctly, a green mark will turn up on the other end of
the Strap release button, please do check it. Picture 11.6
Step 8. Place the child in the seat. Check the height of the shoulder belts. Make sure the straps are not
twisted or hanging somewhere. Fasten the seat belts on the child, making sure that they are well placed and
pull the strap in the centre of the seat to tighten. ( Picture 12)
Please use 3-point safety belts of the car to ensure the safety of the child and to secure the car seat.
Step 1. Remove the seat belts by releasing the shoulder belts from hooks on the back and pull them from the
holes on the back. (Fig 13 a; b)
Step 2. Remove the metal plates of the belts from the bottom of the seat. (Fig. 13 c;d)
Step 3. Press the button on the centre of the seat and pull the adjustment strap under the seat.
Step 4. Place the red guide for the car belt in the corresponding hole on the back of the seat, slightly higher
than the shoulders of the child. (Figure 14)
Step 5. Place the car seat tightly on the car seat facing front in "direction of travel". Make sure the seat is tight
to the vehicle seat.
Step 6. Place the child in the seat.
Step 7. Pass the shoulder belt of the car through the red guide in the back of the seat (Fig. 15 a;b) over the
shoulder of the child (but away from its neck) and under the armrest of the seat. Thread the abdominal belt
under the armrest of the seat and over the lap over the child, then fasten the belt in the buckle of the car until
you hear "click". (Fig.15 c)
Step 8. Make sure the belt is properly positioned across all guides, not twisted and does not interfere with the
child.
"Group II;III" / 15 to 36 kg./ With additional attachment (FIT) and 3 - Point Belt
Step 1. Please repeat the steps from 1 to 4 for installation on the car seat described in Group II / 15 to 36 kg. /
with 3 - Point Belt
Step 2. Please repeat the steps from 1 to 4 for installation on the car seat described in Group I / 9 to 18 kg. /
with ISOFIX and Top Tether .
Step 3. Place the child into the safety seat. Position the shoulder belt through the hook over the shoulder of
the child and lap belt over the seat and lap of the child. Pass the belt through the lower opening into the seat
of the safety seat and fasten the clip to corresponding buckle until click is heard. Pictures 15 a;b;c Check that
the belt buckle is locked by pulling the belt.
INSTALLATION OF SEAT
INSTALLATION OF SEAT With 3 - Point Belt
"Group II" "Group III" / from 15 to 36 kg. /
INSTALLATION OF SEAT
