18. WARNING! Periodically check the belts for wear, paying special attention to the points of attachment,
protections and regulating devices. If the harness / vehicles belts becomes cut or frayed, replace it before
traveling.
19. WARNING: ALWAYS secure your child with the safety belts when using the car seat.
20. WARNING! Do not leave the buckle in a partially closed position and it must only lock when all parts are
engaged. It must be possible to release the child from the restraint immediately in an emergency. Your child
must be taught never to play with the buckle. The buckle is NOT CHILD PROOF
21. WARNING! The baby seat must be secured with car safety belt, even when it is not in use.
An unsecured seat may injure other passengers in the car in an urgent stop.
22. WARNING! Store this child seat in a safe place when it is not being used. Avoid placing heavy objects on
top of it. Do not allow your child seat to come into contact with corrosive substances e.g. battery acid.
23. WARNING! Do not leave your child in this safety seat for a long period of time. By long trips make
more breaks and take out the child from the safety seat.
24. WARNING! Security is only guaranteed if the child restraint is fitted in accordance with these
instructions.
25. WARNING! The instruction must be retained on the child restraint for its life period

WASHING INSTRUCTIONS

1. The car seat can be cleaned using lukewarm water and soap. Do not use aggressive cleaners like
abrasives or thinner.
2. The cover should be washed by hand at a maximum temperature of 30 C. Do not put in the dryer, just
airing it.
3. The plastic parts can be cleaned by using a wettish drapery. Please, do not use any solvate.
TYPES OF APPROVED BELTS TO HAVE IN THE CAR
Your child seat can be installed ONLY in the direction of
movement of the car with the help of 3-point belts!!!
1
Possibility to install ONLY on seats with 3-point seat belts!
CAN NOT BE USED FOR SEATS with 2-point belt!
Parts
Picture 1
1. Carrying handle
2. Belt softener
3. Belt buckles
4. Strap for belts adjustment
5. Button for adjusting the belt (under the cover)
6. Lap belt guide
7. Red button for handle adjusting
8. Diagonal belt guide
Check the height of the shoulder belts
Always check that the shoulder belts are placed at the correct height for your child. Select the height of the
straps according to the child's height. The position of the straps should be at or slightly above the shoulders of
the child. Warning: Do not place the straps too high or so that the child can lean on them!
In the back of the safety seat , there are 3 pairs of holes , which can be used to adjust the shoulder straps to
suit your child's weight (Fig. 2)
Adjusting the height of seat belts
1. Press the button for belts adjusting "5" and at the same time pull both shoulder straps. (Picture 3)
2. Take out the belts "11" of the holes on the back from the front of the seat.
3. Place back the belts in the desired holes on the front side of the backrest and connect them behind the back
with the adjusting strap "4". Make sure the straps are placed on the same level and are not twisted.
Fastening the seat belt
1. Combine the two pieces "E"and "F" at the end of the belt (Picture 6) and place them in the central buckle
"3" until it clicks into place. (Picture 7)
o
9. Openings for shoulder straps
10. Shoulder straps
11. Buckle Pads
12. Head Pillow
13. Baby Insert
14. Cover
15. Canopy
16. Holder of the canopy
17. Canopy frame
13
ECE R44/04
