Heating Circuit Manifold HKV
Installation instructions
Description
Roth heating circuit manifolds are manufac-
tured from corrosion-resistant material and
are designed for use with fl oor heating and
cooling systems. Inlet and return are pre-
mounted on manifold brackets with sound-
insulation.
Scope of delivery
Heating circuit manifold with inlet and return
premounted on manifold brackets, manifold
end pieces (fi lling, venting, locking), venting
key and pressure fi ttings.
Dimensions
Size
2
L
185
With end pieces
245
3
4
5
6
235
285
335
385
295
345
395
445
Technical data
LFR
Material
Number of
heating circuits
Dual spacing
System heating
pipe connection
Inlet/return con-
1" external thread (fl at seal)
nection
Max. pressure
Max. temperature
Valve connection
thread
Valve stroke
Max. fl ow rate/
heating circuit
Water quality
Frost protection
Roth antifreeze FKN 28
Flow rate setting
With adjustable
valve, sight glass
readable, LFR
open to max.
7
8
9
435
485
535
495
545
595
Universal
Brass
2 – 12
50 mm
¾" Euro cone
6 bar
70 °C
M30 × 1.5
3 mm
4 l/min
In acc. w. VDI 2035
With adjust-
able valve, screw
connection open/
closed
open to max.
10
11
12
585
635
685
645
695
745
