Beyerdynamic UNITE CDD-8/4 Kurzanleitung Seite 11

Unite CDD | CDS Cockpit Charger | Unite DS Basic Charger
4.1 How to mount the desktop chargers on a table
The Unite CDS-4/2, Unite CDD-8/4 and Unite DS-4/2 Cockpit desktop chargers have holes on their bottom,
which you can use to attach the chargers on a table with screws using a separate drilling template. Use M3
screws for this. The length of the screws depends on the thickness of the desktop.
• The screws for mounting must not penetrate the housing by more than 6 mm! The height of the rubber
pads is approx. 3.4 mm. If necessary, you can remove the rubber pads before attaching. You will find an
appropriate drawing in the data sheet on the respective product page at www.beyerdynamic.com
Unite CDD-8/4
Bottom of
Holes for mounting on a desktop with M3 screws
Unite CDS-4/2 | Unite DS-4/2
Bottom of
11
