REF.: OCR200
English
INSTRUCTIONS FOR USE AND PRESERVATION
Dear customer,
Thank you for your trust in this Orliman product. You have acquired a quality product with a high
medicinal value. Please, read the instructions carefully. If you have any doubt, get in contact with
your doctor, your orthopaedist specialist or our customer service department. Orliman appreci-
ates your choice and wishes you a speedy recovery.
REGULATION
These products satisfy the European Medical Device Directive 93/42/CEE (RD. 1591/2009). A Risk
Analysis has been carried out (UNE EN ISO 14971) minimising all the existing risks. The trials have
been carried out in accordance with the European regulation UNE-EN ISO 22523 of Prosthesis and
Orthesis.
SUITABLE FOR
Collateral ligament injuries (tears), conservative treatment of instability resulting from combined
knee injuries, ruptured cruciate ligaments combined with collateral ligament injuries (triad) and
postoperative treatment after ligament surgery (ACL) and (PCL).
FITTING INSTRUCTIONS
THE PRODUCT SHOULD BE ADJUSTED BY YOUR ORTHOPAEDIC TECHNICIAN OR IN ACCORDANCE
WITH DOCTOR'S ORDERS.
In order to obtain a greater degree of therapeutic effectiveness in the different pathologies and to
prolong the life and utility of the product, it is fundamental that the correct size adequate for each
patient or user is chosen (enclosed in the packet is a diagram with all the sizes and the equivalent
in centimetres). An excess compression can produce intolerance, therefore we recommend that
the compression be regulated to an optimum degree.
To fit observe the following aspects:
A-Adjustment of flexion and extension:
1–The orthosis is supplied with a set of wedges to adjust flexion and extension.
2–Select the desired wedges.
3–Unscrew the protective cover to enable the selected wedge to be inserted.
4–Once fitted, tighten the screw to fasten the cover and wedge. Repeat the process to adjust the
flexion and extension direction.
B-Fitting instructions for the 0° flexion stop:
1–Unscrew the hinge cover.
2–Remove the 10° extension stop.
3–Replace it with the 0° extension stop.
4–Fully extend the hinge.
5–Insert the 0° flexion stop at the back.
6–Check that the holes in the flexion stop and hinge are aligned.
7–Screw the hinge cover back on.
C-Fitting the orthosis
1–Select the correct side.
2–Completely release the fastening straps to allow the orthosis to be fitted easily.
3–Slide it up until the anatomical axis and the mechanical axis are lined up. At this point, and
thanks to the aluminium, it is recommended, if necessary, to adjust the mediolateral splints to
the morphology of the patient's condyles.
4–Fasten the orthosis by means of the thigh and calf straps. (When fastening the orthosis, follow
the numerical order of the straps from 1 to 6).
5–Finally, check the tightness of the straps and ask the patient to stand and walk, ensuring it is
correctly adjusted and fastened.
D-Fitting the air-cushioned condyle pad:
By means of the hook, position the air-cushioned pad on the desired condyle. Then, inflate with the
pump to obtain the correct compression. Inflation pump included.
PRECAUTIONS
The constructive material is inflammable.
Do not expose these products to situations where they could ignite. If this were the case remove
them quickly and use the necessary measures to put it out. The material used is hypoallergenic,
however we cannot guarantee 100% that in some determined cases it will not produce allergies, if
this occurs, remove the product and see the doctor that prescribed it.
In case of minor irritations due to sweat, we recommend the use of a cotton sock, to separate the
skin from contact with the material. For small inconvenience caused by sweat, we recommend us-
ing an interface to separate the skin from contact with the tissue. If rash, irritation or swelling to
remove the product and consult a doctor or prosthetist. Contraindicated in open scars with swell-
ing, redness and accumulation heat.
RECOMMENDATION-WARNINGS
These products are to be used only by those which have been medically prescribed to do so. Per-
sons unconnected to such prescriptions should not use them. When the product is not being used,
store in its original packaging. In order to dispose of the packaging and the product, strictly com-
ply with the legal norms of your community.
The use of the orthesis is conditioned to the recommendations of the prescribing doctor, therefore
it must not be used for any other means than those prescribed.
For the validity of the guarantee, the issuing establishment should comply with this sheet of in-
structions.
Can´t be used in contact sports.
MANUFACTURE-CHARACTERISTICS
The material features used in production have been tested and approved and meet all the Euro-
pean quality requirements.
All the products are produced with high quality materials and offer an unbeatable comfort and
quality of use. All products offer restraint, stability and compression for the optimum treatment of
the pathologies for which they have been designed.
RECOMMENDATIONS FOR PRESERVATION AND CLEANING
Stick the velcros to each other (if the orthesis has any), wash periodically by hand with a damp
cloth and a neutral soap. To dry the orthesis, use a dry towel to absorb most of the dampness and
leave to dry at room temperature. Do not hang up or iron and do not expose to direct heat sources
such as stoves, heaters, radiators, direct sun light etc. During use or during washing do not use al-
cohols, ointments or dissolvent liquids. If the orthesis is not properly dried any detergent residues
could irritate the skin and deteriorate the product.
GUARANTEES
ORLIMAN, S.L.U. Guarantees all its products, as long as these have not been manipulated or al-
tered from their original state. Does not guarantee those products in which as a result of misuse,
deficiencies or breakage of any kind, its original state has been altered. If you observe any defi-
ciency or anomaly, communicate this immediately to the establishment from which it was obtained
in order for it to be changed.
ORLIMAN, S.L.U. Appreciates your choice and wishes you a speedy recovery.
