2. Information
The mounting-rail cutting and punching device has
been specially designed for processing DIN mount-
ing rails.
2.1

TSDL

t = thickness of material
TS 35/7.5 mm to EN 50022; t = 1.0 mm
TS 35/15 mm to EN 50022; t = 1.5 mm
TS 32 mm to EN 50035; t = 1.5 mm
TS 15/5.5 mm to EN 50045; t = 1.0 mm
Copper earth bars 10 mm x 3 mm
The mounting-rail cutting and punching device can
process only those types of mounting rails, which
are made of steel, described above.
The mounting-rail cutting and punching device can
punch diagonal and longitudinal holes in mounting
rails, which it can also cut to length (12x 6.4 mm di-
agonal and longitudinal holes).
2.2

TSD 35

t = thickness of material
TS 35/7.5 mm to EN 50022; t = 1.0 mm
TS 35/15 mm to EN 50022; t = 1.5 mm
The mounting rail cutters can only be used on the
steel rail types described above.
12
3.

Technical data

3.1 TSDL
Technical data
Length:
Width:
Height:
(without longitudinal
stop, without lever)
Longitudinal stop:
Lever:
Total weight:
3.2 TSD 35
Technical data
Length:
Width:
Height:
(without longitudinal
stop, without lever)
Longitudinal stop:
Lever:
Total weight:
270 mm
205 mm
200 mm
1000 mm
1000 mm
19 kg
142 mm
110 mm
200 mm
1000 mm
1000 mm
11,4 kg
