Battery uptime is low Capacity of internal
battery has degraded
due to wear and tear.
No Live image from Failure on visuali-
the visualization device zation device or
on the displaying unit visualization device
screen connection
The displaying unit
or
and the Ambu
visualization device
No light in the visuali-
have communication
zation device LED
problems
Failure on visualiza-
tion device connector
port
A recorded image is
shown in the Proce-
dure Folder tab
or
A menu box is
blocking the live
16
If you experience that the battery life of the
displaying unit after a full charge is below 1
hour, consider replacing the battery.
Connect/reconnect visualization device
Restart the displaying unit
1. Press the power button to turn OFthe dis-
playing unit
2. When the displaying unit is OFF, press the
power button again to turn it back ON
If the displaying unit does not turn OFF, force
it to turn OFF by pressing the power button for
10 seconds. Press the power button again turn
the displaying unit back on.
If this does not work reset displaying unit
hardware
1. Remove all connected items including the
power supply
2. Press the hardware reset button on the
back of the displaying unit*
3. Reconnect the power supply
4. Press the power button to turn it back ON
Try the other visualization device connector
port.
If an image is obtained from the other con-
nector port, then the first connector port may
need to be replaced.
If none of the connector ports provide an
image, try again using a new visualization
device.
Return to live image by pressing the Live View
tab or
If this does not work restart the
displaying unit
1. Press the power button to turn OFF the
displaying unit
2. When the displaying unit is OFF, press the
power button again to turn it back ON
Live image on the Processing failure
displaying unit screen
is only working while
booting
No image or User Inter- External screen is
face on the external turned OFF
screen
Issue with cable or
cable connection
Wrong input channel
is selected on the
external monitor
SDI – External screen
does not support
3G-SDI
The colours, contrast, Image settings on
sharpness and bright- external screen are
ness look different on not correct
the external screen
than on the displaying
unit screen
Force the displaying unit to turn OFF
1. Press the power button for 10 seconds to
force Turn OFF.
2. Press the power button again to turn the
displaying unit back on.
If this does not work reset displaying unit
hardware
1. Remove all connected items including the
power supply
2. Press the hardware reset button on the
back of the displaying unit*
3. Reconnect the power supply
4. Press the power button to turn it back ON
Turn ON external screen
Check that the SDI or HDMI cable is connected
properly
If possible, try a new cable
Make sure the correct input channel is selec-
ted on the external monitor
Make sure that your external screen supports
3G-SDI (1920 x 1080p 60 fps.)
Adjust the image settings on the external
screen to achieve the desired result Refer to
the Instructions for Use for the external screen
