commeo initial operation/Setting

6.1. Selection of a receiver

By pressing the SELECT button for 3 seconds the transmitter will be
put into the SELECT mode. After the SELECT mode has been star­
ted, the status LED will start to flash quickly and the transmitter will
look for the receiver. The status LED being lit in green indicates that
the receiver has been found and the status LED will flash slowly in
orange.The first receiver completes a brief confirmation run or rather
a short reaction of the end device. If no receivers have been found
this will be indicated by the status LED being lit in red.
Receiver selection with non-programmed transmitter/initial ope-
ration
>1 s
or
Receiver selection with programmed transmitter
1. Select the transmitter channel on which the receiver is
programmed.
2. Push the SELECT button at the transmitter for 3 seconds.
The transmitter is in SELECT mode.
3 s
Note: The receivers found by this method can now be found using
another non­programmed transmitter within 4 minutes. Press the
SELECT button on the additional transmitter for 3 seconds for this
purpose.The transmitter is in SELECT mode. All settings can now be
completed with both transmitters.
1. Interrupt the voltage supply of
the receivers for > 1 second. The
➧
receivers can be found within the
next 4 minutes.
3 s
2. Push the SELECT button at the
transmitter for 3 seconds. The
transmitter is in SELECT mode.
