IDENTIFICATION OF PARTS
IDENTIFICATION OF PARTS
Identification of parts
Front
Control panel
1
Panel
2
Water bucket
3
Water level window
4
Handle (both sides)
5
Rear
Continuous drain hose outlet
1
Caster
2
Power Cord and plug
3
Power cord buckle (placed in the water bucket, used only when
4
storing the unit. Installed as shown Fig.3a))
Pump drain hose outlet (some models without)
5
Air outlet grille
6
Air Tilter
7
NOTE: All the pictures in the manual are for explanation
purposes only. The actual shape of the unit you purchased may
be slightly different, but the operations and functions are the
same.
Accessories:(placed in the water bucket of the unit)
pump drain hose(1pc) (only for the unit with pump featrue)
power cord buckle(1pc)
1
2
3
4
1
2
3
Insert the power cord buckle into the unit.
female threaded end(1pc)(on some models)
14
5
Fig. 2
6
7
4
5
Fig. 3
Fig. 3a
