Smontaggio componenti originali
(versioni Scrambler 1100)
Smontaggio sella conducente
Introdurre la chiave nella serratura (I) e ruotarla in senso orario fino
a sentire lo scatto di sgancio della sella conducente (J). Sfilare la
sella (J) dai fermi anteriori, tirandola all'indietro.
6
6
J
Removing the original components
(Scrambler 1100 versions)
Removing the rider seat
Insert the key into the lock (I) and turn it clockwise until the rider
seat catch (J) disengages with an audible click. Pull the seat (J)
backwards to release it from the front catches.
ISTR 770 / 02
I
