K2
K1
K
Posicionamento da cablagem
Remova a tampa (K2) do conector (K1) da cablagem da unidade
eletrónica (K).
Notas
O comprimento das cablagens representadas na figura deve ser
considerado puramente indicativo.
7
Wiring positioning
Remove the plug (K2) from control unit (K) wiring connector (K1).
Notes
The length of the wirings shown in the figure is to be considered
purely indicative
ISTR 770 / 02
