Baumer EAM360R Montageanleitung Seite 4

12. Montage / Mounting / Montage / Montaggio / Montaje
EAM360-BD
ø 40,5 ±0.2
A-A
A A
2x M3
EAM360-BP
A-A
A
A
4x M2.5 ISO 14583 X8 / 8.8
recom. torque 0.8+/-0.1 Nm
ø d f6
max. ø 18
1.
7,5 ±0.5
1
1.
2x M3 DIN125A
2x M3 DIN912
2.
2
2x M2.5 ISO 14583 X8 / 8.8
recom. torque 0.8+/-0.1 Nm
2.
3.
cylindrical pin ø3h6
3.
M2.5 DIN 912 / 12.9
recom. torque
± 0.15 Nm
0.95
M2.5 DIN 912 / 12.9
recom. torque
±
0.95 0.15 Nm
