Baumer EAM360R Montageanleitung Seite 3

12. Montage / Mounting / Montage / Montaggio / Montaje
EAM360-SW
3x
A
ø0.4 A
A
A
ø 49
EAM360-SW
A
ø0.3 A
B
B
A
3x
ø
ø0.3 A B
ø 6 2
EAM360-K
A
A
A-A
A-A
Detail B
A
0.8 x 30°
4
0.5
1.5
3.6
0.2 A
A-A
A
( 18 ±0.5 )
1.1 ±0.9
10113222
3x M4
4x M3 DIN 912 / 8.8
recommended torque
1.2 +/-0.2 Nm
1*
3
2
2x M4 DIN 916
recommend torque 1.3 +/-0.2 Nm
(with shaft hardness 60 HRC)
4x M3 DIN 912 / 8.8
recommended torque
1.2 +/-0.2 Nm
