Hollow shaft Shrink disc
[mm] dxD [mm]
19x41
41 22x41
25x41
22x50
50 25x50
32x50
22x60
60 25x60
32x60

Components

8
5
1
2
Actuator Screw
M4
R-SMART 120 M4
M4
M5
R-SMART 160 M5
M5
M6
R-SMART 220 M6
M6
7
Num. of Screw Torque
screw class [Nm]
5 10.9
5 10.9
5 10.9
5 10.9
5 10.9
5 10.9
6 10.9
6 10.9
6 10.9
6
3
Smart System
Trasmittable torque
[Nm]
4.3 150
4.3 174
4.3 198
8.5 286
8.5 324
8.5 415
8.5 343
8.5 389
8.5 498
Tab. 3
4
1 Head
2 Pulley unit
3 Driving belt
4 Profile
5 Ball recirculating linear guide
6 Ball recirculating block
7 Carriage
8 Belt tensioner
Fig. 11
