Specifi cations
2.0 Specifi cations
Power:
230V~, 50/60 Hz, 1 ph
Power Supply
Power consumption 1,1 A
0,12 KW
Motor rating
Mains fuses (2x)IEC 127 T 6,3A
Measurements:
>6 sec.
Measuring time
Measuring speed 200 rpm
0–250 mm
Offset
Resolution 1/5 g o 0,05/0,25 oz
Wheel dimensions:
20" (508 mm)
Max. width
Max. diameter 42" (1067 mm)
70 Kg (154 lbs)
Max. weight
Rim width 1-20" (25-508mm)
Rim diameter:
- Automatic / Manual 8-25" / 8-32"
14-26"
- SMART SONAR
Shaft:
Stub shaft diameter 40 mm
Dimensions:
Weight 82 Kg
112 Kg
Shipping weight
Max. Dimensions (wxdxh) 1012x781x1834 mm
1120x1060x1160 mm
Shipping dimensions
Miscellaneous:
Noise level <70 db(A)
2.1 Conditions
During use or long term storage, the conditions should
never exeed:
0-50 °C
Temperature range
Humidity range 10-90%
non condensing
8
