3

Description

3.1

Scope of delivery

The AQUATEC BELUGA is supplied with the following
parts (fig. 1 to fig. 3):
Seat (fig. 1) consisting of:
1 Sideflap
2 Seat plate
3 Hinge for backrest
4 Guide
5 Lifting scissors
6 Track
7 Spindle foot retainer
8 Base plate
9 Gliding shoe
10 Front suction cup (single strap with head)
11 Rear suction cup (double strap with thread)
Backrest (fig. 2) consisting of:
1 Hand control
2 Drive unit cover
3 Curled cable for hand control
4 Backrest
5 Spindle
6 Catch for spindle
7 Clamp ring
8 Spindle foot
9 Battery guide with plug
Battery and charger (fig. 3)
2 Battery
5 Charger
Operating instructions (not illustrated)
Cover (optional)
Seat cover
Backrest cover
3.2

Technical data

Seat width with sideflaps folded out:
Seat width with sideflaps folded in:
Seat height at lowest position:
Seat height at highest position:
Maximum load:
Total weight without battery:
Seat weight:
Weight of backrest:
Weight of battery:
Weight of charger:
Operating voltage:
Charge time as from low-voltage warning: approx. 5 h
The label (fig. 14) provides important information.
The label is on the rear side of the backrest.
12
Downloaded from www.Manualslib.com manuals search engine
4

Transport

Important
●
The backrest is not locked on the seat
when it is folded together.
●
Do not remove the suction cups when
transporting the bathlift.
● You may not transport the device with the
battery inserted into the guide on the back-
rest.
Take the battery out of the guide and always disas-
semble the bathlift into two sections for transport (the
seat and the backrest).
For detailed instructions on how to dismantle the de-
vice, please refer to section 5.4.
5

Setting up

Important!
● Before setting up, inspect all parts for dam-
age caused by transport.
●
During assembly, make sure the parts are
positioned correctly in relation to each oth-
er.
5.1

Recharging the battery

CAUTION!
There is a risk of injury from electric shock.
Only recharge the battery in dry rooms (not
in the bathroom).
Important!
●
Recharge the battery completely each time
before you use the bathlift.
●
Make sure that the voltage specifications
700 mm
shown on the charger correspond to those
380 mm
of the power mains.
60 mm
420 mm
1. Insert the jack plug (1, fig. 3) of the charger (5,
135 kg
fig. 3) into the socket (6, fig. 3) of the battery (2,
12.9 kg
fig. 3).
8.6 kg
4.3 kg
2. Insert the power plug (3, fig. 3) of the charger into
1.6 kg
the power socket.
0.5 kg
The red indicator lamp (4, fig. 3) on the charger stays
12 V
on until the battery is fully recharged.
3. Pull the charger out of the power socket.
4. Disconnect the jack plug of the charger from the
battery socket.
EN
