3. Operating Instructions (continued)
breathing effort. Level 3 (three beeps) is designed to suit the needs of someone engaged in physically strenuous
activity, whilst Level 1 (one beep) is designed to suit the needs of someone engaged in more sedate activity. You
should select the most comfortable setting depending on the type of use. Note: The Respirator is capable of
delivering airflow of at least 180 l/min regardless of the selected Comfort Setting (with a new, unblocked filter
installed).
PRESSURE SENSOR AUTO & MANUAL ZERO CALIBRATION FUNCTION
The CleanSpace2
regulation inside the mask. When there is a variation in the ambient temperature of greater than 20°C between uses
(for example, a variation from -10°C to 10° C), the CleanSpace2
calibrated before use. This can be done in two (2) ways:
1. Auto-Zero Calibration To auto-zero calibrate the pressure sensor, switch the Respirator into Standby Mode for at
least 20 seconds before use.
2. Manual-Zero Calibration Switch the Respirator into Standby Mode. A manual-zero calibration can be performed
by pressing the Power Button and Comfort Airflow Button at the same time. The Buttons should be held until both
the Blue and Red lights are on, after which the Buttons should be released. The lights will stay on for a few seconds
while the Respirator recalibrates. The calibration is completed when the blue and red lights switch off.

4. Fitting and Removing CleanSpace2

STEP 1: PREPARATION FOR USE
Check the CleanSpace2
Respirator should not be used.
Note: The CleanSpace2
mask assembly before using the CleanSpace2
Before use, follow the procedures below:
Unclip and release the filter cover to check there is a filter in place.
•
Check that the battery is charged by pressing the power button. We recommend that a minimum of 2
•
green lights be lit before use. At this level of charge, the Respirator has between 25% and 75% charge
and will typically operate for between 2 and 4 hours. If the battery needs charging, charge the Respirator
for at least 2 hours before use.
Check the mask to ensure that there are no cracks, tears or dirt; check the mask is not distorted.
•
Remove the exhalation valve cover and check the exhalation valve thoroughly for cracks, tears and dirt.
•
Remove any dirt, hairs or anything that could affect the seal of the valve against its seat. Replace the
valve if cracked or torn. Replace the valve cap.
If being used, check the harness is intact and has good elasticity.
•
Flow Rate Test
CleanSpace2 can be tested to check its flow performance against the Manufacturer's Minimum Design Flow (MMDF)
of 120 litre/minute. We recommend that this test is run before each use.
Downloaded from www.Manualslib.com
COMFORT AIRFLOW RESPONSE SETTINGS
™
The CleanSpace2 Respirator has a unique Comfort Setting to complement the AirSensit
Responsive System. The settings on the CleanSpace2
Level 1, 2 or 3. The Level is selected by pressing the fan button and listening for the number of
short beeps emitted. The Comfort Setting changes the way the respirator responds to your
™
Respirator has a pressure sensor zero calibration function to ensure accurate positive pressure
™
Respirator is complete and undamaged. If there are any damaged or defective parts, the
™
Power Unit does not come with a mask. You will need to purchase and fit a CleanSpace
manuals search engine
™
can be adjusted for comfort by selecting
™
Respirator's pressure sensor should be zero
™
™
System.
5 5
English
™
Flow
™
