Multi 340i
Saving data manu-
Saving data auto-

Transmitting data

Transmitting data
automatically
Downloaded from www.Manualslib.com

Saving data

Press the <STO> key in the measuring mode (display No. with the number of
ally the next free memory location). Then, press <RUN/ENTER> and enter the ID
number with < > < >. Terminate the save with <RUN/ENTER>. The instru-
ment changes to the measuring mode.
The Multi 340i portable measuring instrument has an internal data memory.
matically It can store up to 500 datasets. The save interval (Int 1) determines the chro-
Int 1 nological interval between automatic save processes.
To set up the save interval, press <STO> while pressing the <RUN/ENTER>
key (display Int 1) and set the interval with < > < >key . Then, press <RUN/
ENTER> and enter the ID number with < > < >. Change to the last active
measuring mode with <RUN/ENTER>. The automatic save is switched on
(display Auto Store).

Outputting the data memory

You can output the data memory with the <RCL> key. By repeatedly press-
ing the <RCL> key, you reach the following functions:
StO dISP
StO SEr
CAL dISP
CAL SEr
Start the output with <RUN/ENTER>.
Transmitting data
Press the <RUN/ENTER> key in the measuring mode.
manually This manually triggers a data transmission of the current measured value to
the serial interface at any time - independently of the selected intervals.
The interval to the data transmission (Int 2) determines the chronological in-
terval between automatic data transmissions. After the selected interval ex-
Int 2 pires, the current data record is transmitted to the interface. To set up the
transmission interval, press <RCL> while holding down the <RUN/ENTER>
key (display Int 2). Then set the interval with < > < >.

Configuring

Note
You can leave the configuration menu at any time with <M>. The parameters
already changed are stored.
manuals search engine
Output stored data on the display
Output stored data on the serial interface
Output calibration data on the display
Output calibration data on the serial interface
Saving data
11
