3
j
Remove the needle cover.
To avoid contamination or injury, do not
W
touch the introducer needle or cannula
after removing the needle cover.
j
Keep the needle cover. You will need it later
to safely dispose of the introducer needle.
4
Tip: The small tab on the protective film of the
adhesive pad indicates the side to which you
will later connect the transfer set. See
illustration A .
j
Remove both parts of the protective film
from the adhesive pad.
5
j
Pull the pretensioning element upwards,
away from the base, as far as it will go.
Do not slide the safety catch to the
W
position, otherwise the insertion device
will no longer be locked.
6
j
Place the insertion device onto the chosen
infusion site, holding it horizontally. It must
be positioned in such a way that the whole
surface of each contact area on the base of
the insertion device is resting on the skin.
Tip: You should be able to comfortably reach
the side which had the small tab on the
protective film. That is where you will later
connect the transfer set.
j
Slide the safety catch to the
insertion device is now unlocked.
7
j
Press the release button. The cannula is
inserted under the skin.
j
Remove the insertion device.
• If the head set of the infusion set is still
W
in the insertion device, push the
pretensioning element back into the base.
Continue with step
• If the cannula is not properly positioned
under the skin, remove the adhesive pad
from the skin and pull out the cannula.
Start at step 1 with a new head set.
position. The
5
.
