Matrix AUTOMOWTIC MOW 800 Bedienungsanleitung Seite 41

53-4
53-3
53-2
53-1
53-9
53-10
53-11
53-13
53-20
53-5
53-6
53-7
53-8
53-12
53-14
53-18
53-19
53-15
53-16
53-17
CHARGING STATION AND CONTENT
53-1 M3*12 Tapping screws
53-2 Charging pole lower cover
53-3
53-4 Charging pole
53-5 Spring for charging pole
53-6 Upper case of charge station
53-7 Charging plug with wire
Fence line connector
53-8
M4*12 Tapping screws
53-9
Signal light with wire
53-10
PCB for charging station
53-11
53-12
M3*10 Tapping screws
53-13
Charging baseboard
53-14
M4*16 Tapping screws
53-15
Adapter
53-16
Charging cable
53-17
Peg for fence line
53-18
Peg for charging station
53-19
Fence Line
53-20
UK
41
