BLADE REAR WHEEL
Wheel cap
22-1
Wheel decorative part 1
22-2
Wheel decorative part 2
22-3
Wheel decorative part 3
22-1 22-4
Nut
22-5
Round gasket
22-6
22-2
Wheel body
22-7
Rubber cover of the wheel
22-8
22-9
Round retaining ring
22-10
22-3
Rubber band
22-11
M4*16 Flat head screw
22-12
M4*16 Tapping screws
22-13
Walking motor holder
22-14
22-4
Walking motor
22-15
22-5
22-6
22-7
22-8
22-9
22-10
22-11
22-12
22-13
22-14
22-15
