UK
CHARGING STATION (A)
Note: The charging station should be positioned on
the outer edge of the surface to be mowed on the
storage room or a garden house placed like an is-
land in the middle of the surface to be mowed.
It is recommended that the charge station installed in a
and convenient to use the power source. There must
be no obstacles or corners within 2 meters in front.
charging station. The distance to the lawn edge
should not less than 40cm. Then correspond the
fence line to the grooves under the charging station,
Note: The charging station must face the anticlock-
wise direction of the fence line (Abb. B). The charg-
ing station is forbidden to be put on any inclined
surface (Fig. C).
INSTALLATION OF FENCE LINE (E)
a) The fence line starts under the charging station,
wiring in the anticlockwise direction along the
lawn edge. It ends at the back side of the charging
station.
b) The fence line must pass through the middle of
the charging station, and forward at least 2 me-
ters.
c) The slimmest distance of wirings must be at least
1.5 meters interval.
d) The fence line corner must have an inner angle of
at least 120° and make sure the line lengths be-
tween these two angels should be enough long,
the minimum length is 50 cm (Fig. G).
tree in the lawn, isolate it as semi-ring-like island
or ring-like island with the fence line to avoid any
hit (Fig. F).
the charging station, the distance of the rest fence
line to the lawn edge is not less than 30cm (Fig. A).
the provided pegs. It is recommended that the
pegs are inserted every 1 meters. The pegs can
be put even closer each other if the ground eleva-
terminals respectively for both front and tail ends
30
(Fig. I). Strip the terminals to reveal the copper
lines for 2-3cm (Fig. J). Remove the nuts (Fig. K),
fasten the copper lines on copper conductors
(Fig. L). Then tighten the nuts (Fig. M). Front tail
connect with the red pole, rear tail connect with
the black pole. When the charger is connected to
the charging station and the fence line starts to
Note: Do not fold or repeat wiring with the rest
fence line. Cut it instead (Fig. I)
MOWING HEIGHT (O)
The mowing height can be adjusted from 2.5cm to
5.5cm by adjusting knob beside the display panel.
We suggest that the height of grass should not be
higher than 15cm. If the grass is too high, the lawn
machine may not be applicable. Please cut the grass
to a suitable height before using the machine. And
for better cutting the slope angle had better not
higher than 28°.
CHARGING (N)
The mower can be charged in the charging station.
contact with the respective paddles of the charging
for charing automatically when it needs to recharge.
The charger plugs must be well connected to the
charging station and tighten the nuts.
The two paddles of the charging station are electri-
To avoid short circuit, they must never be touched
with conductor when the charger is connected to
the charging station.
The mower cannot work when it stand on the
charge station.
