I/O Panel
1
15
14
No. Description
1
USB 2.0 Ports (USB01)
2
USB 3.0 Ports (USB3_5_6)
3
LAN RJ-45 Port*
4
Side Speaker (Gray)
5
Rear Speaker (Black)
6
Line In (Light Blue)
7
Front Speaker (Lime)**
8
Microphone (Pink)
* here are two LEDs on the LAN port. Please refer to the table below for the LAN port LED indications.
ACT/LINK LED
SPEED LED
LAN Port
Activity / Link LED
Status
Description
Of
No Link
Blinking
Data Activity
On
Link
2
13
12
11
No. Description
9
Central / Bass (Orange)
10
USB 3.0 Ports (USB3_1_2)
11
HDMI Port
12
DisplayPort 1.1a
13
DVI-D Port
14
PS/2 Mouse/Keyboard Port
15
DC Jack***
Speed LED
Status
Of
Orange
Green
N3150DC-ITX
4
6
3
5
7
10
9
8
Description
10Mbps connection
100Mbps connection
1Gbps connection
3
