CIAT company thanks you for the purchase of a
UTA COMPACT which, we hope, will give you entire
satisfaction. To guarantee its working, connections
(electric, fluids,...) must comply with state-of-the-art
installation rules and country regulations. The
maintenace of you terminal unit will take into
account the recommendations mentionned in the
present brochure.
UTA COMPACT unit
description (Fig.1)
1 : Fan assembly and filter access panel
2 : Coil hydraulic connections
3 : Coil air vents
4 : Drain pan
5 : Metallic electrical box
6 : Air filter
7 : Pre-cut fresh air inlet
8 : Fixations holes ∅12x30mm
9 : Elastic dampers (accessory)
Models (Fig.2)
UTA COMPACT in four standard models :
I : Steel sleeve on inlet and outlet for rectangular
ducts.
Y : Steel sleeve on inlet for rectangular duct +
discharge plenum with flanges for circular ducts.
H : Return and discharge air plenum with flanges for
circular ducts.
U : Return and discharge air plenum with side
flanges for circular duct.
Unit Réception
The unit is supplied in labelled cardboard packaging
with all the unit's characteristics (type, model, SO
number,...) enabling you to identify it. Each unit has
an identification plate marked with an identification
number to be given in all correspondence.
When the packages are received, the inspection of
the condition of the goods at arrival is the recipient's
entire responsibility :
For shortages, the customer must mention the
exact number of packages received.
In the event of defects on the units, the customer
must describe the damage observed on the receipt
in the presence of the delivery person, and only
sign the receipt after having done this.
IMPORTANT : These remarks, in compliance with
article 105 of the French trade code, must be
confirmed by registered letter to the transport
operator within 3 working days. The terms
"reservations" and "subject to unpacking" are not
valid. The customer must unpack the goods in the
presence
of
the
reservations at delivery are required.
delivery
person.
Specific
ENGLISH
Handling
Caution : The unit must be handled with care. With
shocks there is a risk of twisting the frame and
damaging the fan-motor assembly. If possible the
unit should be lifted using the fixation holes. If this
lifting means cannot be used, the operation can be
carried out using a fork-lift.
Putting the unit in place
The unit should be installed inside the false ceilling.
If the unit isn't ducted to the inlet, make sure to
respect a distance between the wall and the rear of
the unit (X=250 mm mini) (fig.3).
The unit should be fixed to the ceiling using
threaded rods (not supplied), use the 4 fixation
holes with elastic dampers (accessory) (fig.1-9).
Check the unit with a spirit level.
If a control with wall thermostat is used, do not
expose it to the sun, behind a door, nor above an
apparatus discharging heat, but rather on an interior
wall to 150 cm height.
Aeraulic connections
Follow the recommendations relating to the aeraulic
balancing of the units and sealing possibilities of Y
model's discharge spigots, according to sizes
(fig.4).
Recommanded air flow for outlet :
- ∅ 200mm
- ∅ 250mm
Caution : Spigots on H or U models must not be
blocked, neither on the discharge nor on the intake
sides.
hydraulic connections
The coils are equipped with monobloc "female"
threaded double hydraulic connections (fig.6a), air
vent and drain.
To fit a control valve with a flat seal, a CIAT
connector is necessary (fig.6b). The CIAT hydraulic
connectors are equipped with a flange to maintain
the gasket in position during tightening. The table
(fig.6d) gives the CIAT recommendation concerning
the joints.
Installation :
In order not to deteriorate this connector or the
CIAT valve, do not apply a torque superior to 3.5
daN.m. Respect the valve assembly direction.
On these CIAT valves, the circulation must occur
from A → AB (A being connected on the coil side
and AB on the hydraulic pipework). The maximal
admissible differential pressure on our valves (open
or closed) is 100 kPa. CIAT recommends not to
overpass 60 kPa.
12
400m
3
/h.
600m
3
/h.
