Specifications & Ordering details
Luminous ux
Operation
Autonomy
Testing system
Degree of protection
Connection terminals
Rated voltage
Housing material
Housing color
Insulation class
Permissible ambient temperature
Headlamp light source
Ordering details
Order code
Order code
Description
BT1SC-B1
BeamTech Small 1x250lm
BT1SD-B3
BeamTech Small 1x250lm
BT1SC-B1CGL
BeamTech Small 1x250lm CGL+
BT1SD-B3CGL
BeamTech Small 1x250lm CGL+
BT1SC-D1
BeamTech Small 1x500lm
BT1SL -D2
BeamTech Small 1x500lm
BT1SL -D3
BeamTech Small 1x500lm
BT1SC-D1-AT
BeamTech Small 1x500lm AT
BT1SL -D3CGL
BeamTech Small 1x500lm CGL+
BT2SC-D1
BeamTech Small 2x250lm
BT2SL -D2
BeamTech Small 2x250lm
BT2SL -D3
BeamTech Small 2x250lm
BT2SC-D1CGL
BeamTech Small 2x250lm CGL+
BT2SL -D3CGL
BeamTech Small 2x250lm CGL+
BT2SL -F1
BeamTech Small 2x500lm
BT2SL -F1-AT
BeamTech Small 2x500lm AT
BT2SL -F1CGL
BeamTech Small 2x500lm CGL+
BT2SL -F2
BeamTech Small 2x500lm
BeamTech
250lm, 500 lm, 1.000 lm
Non-Maintained
1 or 3 hours
test button, test by Telecommand
IP65 ( xed mount, rigid cable conductors) & I 07
up to 1,5 mm screwless pushwire & multicore,
In & Out mains terminals (L, N, E)
CGLine+ bus through-wiring up to 2,5 mm
220-240 VAC, 50/60Hz
Polycarbonate (850 °C glow wire resistant)
RAL9003
Class II
+5°C to +40°C (NiCd) / +5°C to +50°C (LiFePo)
12 LEDs Wide / 12 LEDs Narrow (4W max)
2.3VA/1.6W
3VA/2.4W
2.3VA/1.6W
3VA/2.4W
2.3VA/1.6W
5VA/4.5W*
5VA/4.5W*
2.3VA/1.6W
5VA / 4.5W*
2.3VA/1.6W
5VA/4.5W*
5VA/4.5W*
2.3VA/1.6W
5VA/4.5W*
5VA/4.5W*
5VA/4.5W*
5VA/4.5W*
5VA/4.5W*
* while charging, less than 1W in standby
1-05-263 - Installation & Operation manual
250 Lm
1h
NiCd 4Cs, 4.8V / 1.7Ah
250 Lm
3h
NiCd 3D, 3.6V / 4Ah
250 Lm
1h
NiCd 4Cs, 4.8V / 1.7Ah
250 Lm
3h
NiCd 3D, 3.6V / 4Ah
500 Lm
1h
NiCd 4Cs, 4.8V / 1.7Ah
500 Lm
2h
LiFePo4 6.4V / 3.2Ah
500 Lm
3h
LiFePo4 6.4V / 3.2Ah
500 Lm
1h
NiCd 4Cs, 4.8V / 1.7Ah
500 Lm
3h
LiFePo4 6.4V / 3.2Ah
500 Lm
1h
NiCd 4Cs 4.8V / 1.7Ah
500 Lm
2h
LiFePo4 6.4V / 3.2Ah
500 Lm
3h
LiFePo4 6.4V / 3.2Ah
500 Lm
1h
NiCd 4Cs 4.8V / 1.7Ah
500 Lm
3h
LiFePo4 6.4V / 3.2Ah
1.000 Lm
1h
LiFePo4 6.4V / 3.2Ah
1.000 Lm
1h
LiFePo4 6.4V / 3.2Ah
1.000 Lm
1h
LiFePo4 6.4V / 3.2Ah
1.000 Lm
2h
LiFePo4 6.4V / 3.2Ah
www.eaton.com
K
12
