Do you need more help?

If the suggestions in the previous section did not rectify your problem please contact us. The following
information would help us:
•
What external devices are connected?
•
What messages appear on the screen?
•
When operating the device, at which step did the problem occur?
•
If you have a PC connected to the device:
– How is your computer configured?
– What software were you using when the problem occurred?
•
What steps have you already taken to try and rectify the problem?
•
Please provide your customer number if you have one.

LCD TV pixel faults

Despite the most modern production methods, the highly
complex technology involved in producing this type of device
means there may be individual or multiple pixel drop-outs (dead
pixels). This is rare, however.
For active matrix TFTs with a resolution of 1440 x 900 pixels,
which are each made up of three sub-pixels (red, green, blue),
there are a total of approx. 3.9 million control elements in use.
Occasionally one or more pixels can fail or become incorrectly
controlled because of this very high number of transistors and the
associated extremely complex manufacturing processes used.
Description
Bright sub-pixel
Separation
Dark sub-pixel
Separation
Total number of bright and dark sub-pixels
The table describes the maximum number of pixel failures allowed on the screen, without a warranty claim
arising. A warranty claim can be made in some cases if the above number of defects in a category is exceeded.
34
1 sub-pixel
Two adjacent
(horizontal/vertical)
3 adjacent
(horizontal/vertical)
Minimum distance between bright and
dark sub-pixels
Single
2 adjacent
3
Minimum distance between bright and
dark sub-pixels
Accepted number
≤ 3
≤ 1
0
≥ 15 mm
≤ 3
≤ 1
≤ 0
≥ 15 mm
≤ 5
