Final Installation - Thermoflow 3-In-1 Montage- Und Betriebsanweisung, Garantiebedingungen

DE
See image 4
The cold water supply should be connected to the inlet on the right of the device (blue = cold
water). The hot water pipe is installed on the left. Make sure the connections are watertight!
T o prepare the connection to the water supply T eflon tape must be used for sealing the pipes.
See image 5
The electrical connection should be made by a qualified electrical
installer, in accordance with the relevant regulations (IEEE, etc.).
The device has been prepared for connection to the electrical supply.
See image 6
Cut the cable to the required length and connect it to the terminal strip. Use the supplied
cable boot to obtain a good seal.
See image 7
This appliance should be earthed.
See image 8
The connections are protected to IP24 (splash proof).
Before the first connection to the power supply, the power of the water heater should be
set by the authorised electrical installer. The setting of 18, 21 of 24 kW must comply with
the specifications of the electrical network.

Final installation

• Open the cold water stop valve.
• Install the top of the housing.
• Insert the fixing screw at the bottom.
Commissioning
• Fill the device and vent it by opening a hot water tap connected to it.
• Only switch on the electrical supply once the device is clear of any
air.
• Check the operation of the device.
Frost
The device should be installed in a vertical position in a room protected
from frost and in the proximity of the water connections.
In case the room cannot be protected against frost, the device should
not be installed in this room. Should the device be installed in such a
room, the device should be emptied before the frost danger will occur.
Do not switch on if there is a possibility that the water in the device is
frozen.
